Technical parameter
| Model | CUT-40 | CUT-50 | GUT-80 | CUT-100 | CUT-120 |
| Power Voltage(V) | 1PH 230 | 3PH 400 | 3PH 400 | 3PH 400 | 3PH 400 |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 4.8 | 7.9 | 11.8 | 15.2 | 29.2 |
| No-load Voltage(V) | 230 | 270 | 270 | 280 | 320 |
| Efficiency(%) | 85 | 85 | 85 | 85 | 85 |
| Air Pressure(Pa) | 4.5 | 4.5 | 4.5-5.5 | 4.5-5.5 | 4.5-5.5 |
| Cutting Thickness(CM) | 1-16 | 1-25 | 1-25 | 1-40 | 1-60 |
| Rated Duty Cycle(%) | 60 | 60 | 60 | 60 | 60 |
| Protection Class | IP21S | IP21S | IP21S | IP21S | IP21S |
| Insulation Degree | F | F | F | F | F |
| Weight(Kg) | 22 | 23 | 26 | 38 | 45 |
| Dimension(MM) | 425“195*420 | 425“195“420 | 425“195*420 | 600*315*625 | 600“315“625 |
